G0955 60-gallon 5 Hp Extreme Series Air Compressor

The Grizzly G0955 60-Gallon 5 HP Extreme Series Compressor operates at low RPMs for extended life and low maintenance. The 5 HP 230V motor operates with a maximum pressure of 150 PSI. This compressor delivers 18 CFM at 90 PSI and 20 CFM at 40 PSI.

Providing more complete motor overload protection than a magnetic starter that only senses current, the motor senses both temperature and current. A wired-formed belt guard provides more efficient cooling to keep the unit from overheating.

The 60-gallon vertical air tank has been ASME certified to meet safety and quality standards. The one-stage cast-iron oil-lubricated pump operates at high pressure providing increased volume when you need it.

Additional features include a tank pressure gauge, on/off switch, 1/2" NPT threaded fitting, and an easily accessible oil level sight glass.

Like all Grizzly air compressors, the G0955 comes with a 1-year warranty which covers parts and assures the unit is free from factory defects.

The Grizzly Customer Service and Technical Support Teams are U.S.-based. To order parts, or other services and inquiries, contact Mega Compressor at (832) 415-6995.

• Motor: 5 HP, 230V, single-phase, 22.5A
• Airflow capacity: 18 CFM at 90 PSI and 20 CFM at 40 PSI
• Maximum air pressure: 150 PSI
• Overall size: 30" W x 22" D x 68" H
• Approximate shipping weight: 345 lbs.

• Large oil level sight glass
• Ball-valve drain and output control
• Wired-formed belt guard for more efficient cooling
• Fan pulley and cooling fin design to keep compressor cool
• W-cylinder cast-iron air compressor pump
• Made and assembled in the USA with global parts
• ASME-certified 60-gallon tank
